| Part Number | Location | Trail Forged Part Applications | Mount Width | Bolt Size | Shank Size | Rebuild Kit |
|---|---|---|---|---|---|---|
| CE-9114 | Lower Control Arm | All lower control arms up to 2018 JK, and JL rear lower. NOT for JL front or any JT. | 2.625″ | 9/16″ / 14mm | 1.25″-12 R | CE-9110RK |
| CE-9114-28 | Lower Control Arm | JL Front lower, JT front & rear. | 2.625″ | 5/8" / 16mm | 1.25″-12 R | CE-9110RK |
| CE-9112SP | Upper Control Arm, 10mm bolt | XJ/MJ/ZJ/TJ/LJ/WJ Front Upper, bolt in ZJ/TJ/LJ Rear Upper | 2.0″ | 10mm | 3/4″-16 R | CE-9112RK |
| CE-9112SP-12 | Upper Control Arm, 1/2″ bolt | XJ/MJ/ZJ/TJ/LJ/WJ Front Upper, 1/2" Upgrade JK Front Upper | 2.0″ | 1/2″ | 3/4″-16 R | CE-9112RK |
| CE-9117N | Upper Control Arm, Rear | WJ rear upper long arms(confirm shank size) | 2.625″ | 9/16″ / 14mm | 7/8″-14 R | CE-9110NRK |
| RJ-331601-102 | Rear Upper Control Arm | JL/JT Rear Upper arms | 2.365" | 9/16″ / 14mm | 7/8″-14 R | CE-9110NRK |
| CE-9116NL-13 | Track Bar | TF Trackbars for WJ applications | 1.6″ | 9/16″ / 14mm | 7/8″-14 LEFT | CE-9112NRK |
| CE-9112N75-17 | Track Bar | Rough Country Trackbar* | 1.6" | 1/2" | 3/4″-16 R | CE-9110NRK |
| CE-9112N75-13 | Track Bar | Rough Country Trackbar* | 1.6" | 9/16" | 3/4″-16 R | CE-9110NRK |
Notes:
- These DO NOT come with jam nuts, if you want a replacement jam nut, check the jam nut option box
- These come greased. They have a zerk grease fitting, and do not require greasing before service. ONLY grease with a manual grease gun, never a powered grease gun.
- If you have extra long shank lower control arm flex joints, see the Enduro Joint Forged Rod End, Long Shank page.
- Note for RC Trackbar customers!!! Check your bolt sizes. Any time you can upgrade to a larger bolt, we suggest doing so. We sell 9/16″ bolt upgrade kits here
| Joint Size | CE-9114, CE-9114-28, CE-9112SP, CE-9112SP-12, CE-9117N, RJ-331601-102, CE-9116NL-13, CE-9112N75-17, CE-9112N75-13 |
|---|
2 reviews for Johnny Joint Forged Rod End
Add a review
Related products
$259.00
-
Price range: $21.00 through $25.00
-
-
$37.75
-
Price range: $12.00 through $25.00
-
-
$3.45
-
William A (verified owner) –
I got these for my long arm kit due to the bushings being bad. Trail forged is a great company to deal with and is always top notch parts and customer service will deal with this company many more times.
wohoman2005 (verified owner) –
These things are awesome, I got the shorter ones they fit perfect on my 4 inch long arm, rough country, and what I pulled out was the Longshank ones from rough country just to clarify, I bought the nut, and a new nut and bolt just to have all new hardware. These things went in flawlessly. I am so glad I bought these. These are an awesome replacement. I did a test drive no more clunking..
